Cation vs Anion: Definition, Chart and the Periodic Table

A cartoon style image showing chlorine taking an electron from sodium.
Credit: Technology Networks
Listen with
Speechify
0:00
Register for free to listen to this article
Thank you. Listen to this article using the player above.

Want to listen to this article for FREE?

Complete the form below to unlock access to ALL audio articles.

Read time: 6 minutes

Introduction to ions. Credit: Khan Academy via YouTube


If an atom, or atoms, has a balanced number of electrons (negative charge) and protons (positive charge) they are neutral overall. However, if they are not balanced, they will be charged. These charged species are called ions.



Cations vs anions – what’s the difference?

Cations are ions that are positively charged. Anions are ions that are negatively charged. Ions are charged atoms or molecules. If a balanced atom loses one or more electrons, it will become a positively charged cation. If a balanced atom gains one or more electrons, it will become a negatively charged anion.


What is a cation?


A cation has more protons than electrons, consequently giving it a net positive charge. For a cation to form, one or more electrons must be lost, typically pulled away by atoms with a stronger affinity for them. The number of electrons lost, and so the charge of the ion, is indicated after the chemical symbol, e.g. silver (Ag) loses one electron to become Ag+, whilst zinc (Zn) loses two electrons to become Zn2+.


The energy shift involved when an atom becomes a cation is shown.Figure 1: The generation of a cation. Credit: Technology Networks.


What is an anion?


An anion has more electrons than protons, consequently giving it a net negative charge.
For an anion to form, one or more electrons must be gained, typically pulled away from other atoms with a weaker affinity for them. The number of electrons gained, and so the charge of the ion, is indicated after the chemical symbol, e.g. chlorine (Cl) gains one electron to become Cl-, whilst oxygen (O) gains two electrons to become O2-.

The energy shift involved when an atom becomes a cation is shown.

Figure 2: The generation of an anion. Credit: Technology Networks.


Cation vs anion chart


The main differences between cations and anions are summarized in the table below.

Cation

Anion

Charge

Positive

Negative

Electrode attracted to

Cathode (negative)

Anode (positive)

Formed by

Metal atoms

Non-metal atoms

Examples

Sodium (Na+), Iron (Fe2+), Ammonium (NH4+)

Chloride (Cl-), Bromide (Br-), Sulfate (SO42-)


Metallic atoms hold some of their electrons relatively loosely. Consequently, they tend to lose electrons and form cations. Conversely, most nonmetallic atoms attract electrons more strongly than metallic atoms, and so gain electrons to form anions. Therefore, when atoms from a metallic and a nonmetallic element combine, the nonmetallic atoms tend to draw one or more electrons away from the metallic atoms to form ions. These oppositely charged ions then attract one other to form ionic bonds and produce ionic compounds with no overall net charge. Examples include calcium chloride (CaCl2), potassium iodide (KI) and magnesium oxide (MgO).


Cation vs anion periodic table


It can be possible to predict whether an atom will form a cation or an anion based on its position on the periodic table. Halogens always form anions, alkali metals and alkaline earth metals always form cations. Most other metals form cations (e.g. iron, silver, nickel), whilst most other nonmetals typically form anions (e.g. oxygen, carbon, sulfur). However, some elements are capable of forming both cations and anions given the right conditions. One example is hydrogen, which may gain (H-) or lose (H+) an electron, forming hydride compounds such as ZnH2 (where it is an anion) and hydron compounds such as H2O (where it is a cation).


Elements in group 18 of the periodic table – the “noble gases”, tend not to form ions due to the arrangement of their electrons which makes them generally unreactive.

The periodic table.Figure 3: The periodic table. Credit: Technology Networks.


Cation vs anion size


Cations and anions come in many sizes across the periodic table.


Utilizing ionic properties


Ionic properties can be exploited by chemists for a range of purposes. Ion-exchange chromatography for example relies on the affinity of the molecules being separated for the stationary phase based on their charge properties to enable separation.


Ionic properties are central to the function of batteries too. Batteries have two electrodes made of conductive material, the cathode which is the positive end where the electrical current leaves/electrons enter, and the anode where the electrical current enters/ electrons leave. In between the electrodes is an electrolyte liquid or gel that contains charged particles – ions. As this ionic substance reacts with the electrodes it generates electrical current. In single use, dry cell batteries, zinc is commonly used as the anode whilst manganese dioxide is a popular choice for the electrolyte cathode. The zinc anode also acts as the battery’s container in zinc-carbon batteries so as it oxidizes during use, the contents can start to leak over time.

A zinc-carbon dry cell battery (left) and alkaline battery (right) are compared.

Figure 4: A zinc-carbon dry cell battery (left) and alkaline battery (right). Credit: Technology Networks


In rechargeable batteries, such as many lithium-ion batteries, this chemical process is reversible and the internal structure different which allows the batteries to be recharged.


Due to the ionic properties of salt water,
scientists are now striving to exploit the ionic electricity-generating potential of salinity gradients where salt water and fresh water mix as a green source of energy generation for the future.
