E-Waste Finds a Second Life as a Protective Metal Coating
News

E-Waste Finds a Second Life as a Protective Metal Coating

E-Waste Finds a Second Life as a Protective Metal Coating
News

E-Waste Finds a Second Life as a Protective Metal Coating

The material (thick gray line in the center of the image) derived from e-waste remained intact when indented, and increased the hardness of the steel below it. Credit: Adapted from ACS Omega 2020, DOI: 10.1021/acsomega.0c00485.
Read time:


Want a FREE PDF version of This News Story?

Complete the form below and we will email you a PDF version of "E-Waste Finds a Second Life as a Protective Metal Coating"

First Name*
Last Name*
Email Address*
Country*
Company Type*
Job Function*
Would you like to receive further email communication from Technology Networks?

Technology Networks Ltd. needs the contact information you provide to us to contact you about our products and services. You may unsubscribe from these communications at any time. For information on how to unsubscribe, as well as our privacy practices and commitment to protecting your privacy, check out our Privacy Policy

A typical recycling process converts large quantities of items made of a single material into more of the same. However, this approach isn’t feasible for old electronic devices, or “e-waste,” because they contain small amounts of many different materials that cannot be readily separated. Now, in ACS Omega, researchers report a selective, small-scale microrecycling strategy, which they use to convert old printed circuit boards and monitor components into a new type of strong metal coating.

In spite of the difficulty, there’s plenty of reason to recycle e-waste: It contains many potentially valuable substances that can be used to modify the performance of other materials or to manufacture new, valuable materials. Previous research has shown that carefully calibrated high temperature-based processing can selectively break and reform chemical bonds in waste to form new, environmentally friendly materials. In this way, researchers have already turned a mix of glass and plastic into valuable, silica-containing ceramics. They’ve also used this process to recover copper, which is widely used in electronics and elsewhere, from circuit boards. Based on the properties of copper and silica compounds, Veena Sahajwalla and Rumana Hossain suspected that, after extracting them from e-waste, they could combine them to create a durable new hybrid material ideal for protecting metal surfaces.


To do so, the researchers first heated glass and plastic powder from old computer monitors to 2,732 F, generating silicon carbide nanowires. They then combined the nanowires with ground-up circuit boards, put the mix on a steel substrate then heated it up again. This time the thermal transformation temperature selected was 1,832 F, melting the copper to form a silicon-carbide enriched hybrid layer atop the steel. Microscope images revealed that, when struck with a nanoscale indenter, the hybrid layer remained firmly affixed to the steel, without cracking or chipping. It also increased the steel’s hardness by 125%. The team refers to this targeted, selective microrecycling process as “material microsurgery,” and say that it has the potential to transform e-waste into advanced new surface coatings without the use of expensive raw materials.

Reference
Rumana Hossain and Veena Sahajwalla. Material Microsurgery: Selective Synthesis of Materials via High-Temperature Chemistry for Microrecycling of Electronic Waste. ACS Omega 2020, 5, 28, 17062–17070, July 13, 2020, https://doi.org/10.1021/acsomega.0c00485

This article has been republished from the following materials. Note: material may have been edited for length and content. For further information, please contact the cited source.
