Infrared Sensor Could Speed up Drug Discovery
News Jul 24, 2018 | Original Story by Meike Drießen for Ruhr University Bochum.
Using an infrared sensor, biophysicists at Ruhr-Universität Bochum (RUB) have succeeded in analysing quickly and easily which active agents affect the structure of proteins and how long that effect lasts. Thus, Prof Dr Klaus Gerwert and Dr Jörn Güldenhaupt performed time-resolved measurements of the changes to the structure of protein scaffolds, which were triggered by the active agents. Their methods might one day help develop drugs with little side effects in a quick and targeted manner. The team published a report on their research, which was conducted under the umbrella of the EU-funded programme Innovative Medicines Initiative in the project Kinetics for drug discovery (K4DD), in the journal Angewandte Chemie on May 17, 2018.
Active agents can alter the structure of target proteins
The efficacy of many drugs is based on the fact that they manipulate the metabolism of cells by inhibiting the activity of specific proteins. To this end, the drug molecule must bind to the respective target protein, while the active agent more often than not settles in the functional compartments of proteins, which are often hollow like a pouch.
In the case of some active agents, binding to the target protein additionally alters the structure of the protein surface. Following so-called conformational change, new surface areas and binding pouches become accessible, and an active agent can be further adapted to match them. This process often results in a better selectivity of active agents, thus reducing side effects.
New method facilitates rapid measurements
“The way an active agent affects the structure of its target protein has so far been analysed using time-consuming and material-intensive methods, which may provide extremely detailed spatial information, but which don’t yield results until weeks or even months later,” explains Jörn Güldenhaupt.
Developed by the researchers from Bochum, the new method provides information on structural changes within minutes, and it can even narrow down the type of structural change. The sensor is based on a crystal that is permeable for infrared light. The protein is bound on its surface. Infrared spectra are recorded through the crystal, while the surface is rinsed with solutions with or without any active agents. The sensor detects changes to the protein’s spectral area that is structure-sensitive, i.e. the so-called amid region, which is characteristic for the scaffold of a protein. If any changes occur, it is obvious that the active agent has altered the shape of the protein.
Example: heat shock protein
In collaboration with the company Merck, the team demonstrated the reliability of this method by analysing the way two different active agent groups affected the heat shock protein HSP90. It is a folding helper that assists newly generated proteins in the cell to form the correct three-dimensional structure. Due to their extremely active metabolism, tumour cells require it very urgently. HSP90-inhibiting active agents constitute an approach for the development of drugs that stop tumour growth.
Binding period determines how often a drug has to be taken
The rate at which a drug molecule disengages from the target protein corresponds with the efficacy period of the drug in the body. Active agents with a high complex life span are bound to the target protein for a long time, thus remaining effective for a long time. Tablets containing such active agents have to be taken only once a day, for example, and often have fewer side effects. “Since our sensor acts as a flow system, we can rinse the active agents off the target protein after binding and, consequently, measure how the efficacy changes over time,” explains Klaus Gerwert.
This article has been republished from materials provided by the Ruhr University Bochum. Note: material may have been edited for length and content. For further information, please contact the cited source.
Jörn Güldenhaupt, Marta Amaral, Carsten Kötting, Jonas Schartner, Djordje Musil, Matthias Frech, Klaus Gerwert: Ligand‐induced conformational changes in HSP90 monitored time resolved and label free – towards a conformational activity screening for drug discovery, in: Angewandte Chemie International Edition, 2018, DOI: 10.1002/anie.201802603.
