Pittcon 2020: First Multimodal Raman Microscope for UV-vis-NIR Imaging

Pittcon 2020: First Multimodal Raman Microscope for UV-vis-NIR Imaging content piece image
Listen with
Register for free to listen to this article
Thank you. Listen to this article using the player above.

Want to listen to this article for FREE?

Complete the form below to unlock access to ALL audio articles.

Read time: 2 minutes

HORIBA Scientific, specialists in measurement and analysis solutions for research and industry, and in Raman spectroscopy, has announced the introduction of LabRAM Soleil™, a multimodal Raman microscope designed for UV-VIS-NIR imaging at Pittcon 2020, in Chicago, IL.

The LabRAM Soleil™ confocal Raman imaging microscope, part of HORIBA’s LabRAM spectroscopy series, comes complete with ultrafast imaging, advanced automation features, intuitive software and a robust design to advance researchers’ analyses.

Ultrafast Imaging

  • LabRAM Soleil™ multimodal imaging performance levels give researchers the ability to observe samples in different modes for all types of applications, with an innovative design of the optical compartments, its optimized broadband dielectric mirrors and a high throughput spectrometer.
  • HORIBA’s patented SmartSampling™ technology, added to the instrument’s stability and precision levels, makes hyperspectral mapping much faster with an image-compression algorithm. These new and smart ultrafast imaging capabilities let users map samples up to 100 times faster than before.
  • HORIBA’s QScan™ patented confocal imaging system, is a high-quality optical system that enables scanning of the excitation laser over the sample surface. Benefits include: High confocality of the image multilayer sample, the ability to map the sample without moving it, and more agility with point-and-shoot operation, directly on the video image.

Advanced Automation

Advanced automated features are huge time savers and greatly improve user experience. LabRAM Soleil™ offers benefits such as true self-operation, remote maintenance and instant objective recognition.

The user can speed up analyses with a fully-automated, featured-packed instrument:

  • Up to 6 motorized lasers (4 built-in, 2 external)
  • Up to 6 spectroscopic modes (among which: Raman, ULF, photoluminescence, up-conversion luminescence) allow to operate in the specific context of the application domain, with a high degree of flexibility.

LabRAM Soleil™ comes with the latest, built-in, LabSpec™ 6 Spectroscopic Suite, designed to enable faster data acquisition routines and analyses. The intuitive interface aims to maximize the full power of the system, enabling various software configurations to suit customer-specific needs. LabSpec™ 6 offers a brand-new series of apps, downloadable from the App Store, which could make Raman imaging much more accessible than ever before. At every step of the workflow, a new app developed by the HORIBA team facilitates the image generation process, from adjusting the focus to optimizing parameters, to interpreting Raman images and producing customized reports. Apps include:

  • EasyImage™ to simplify the entire workflow.
  • MVAPlus™ for a full range of multivariate analyses, enabling easy and efficient analysis of chemical components.
  • Know-It-All™ allows a large database, including the HORIBA database, to combine all know-how assets in one place: This is designed to accelerate the identification and characterization process.
  • 3D Volume™ intends high precision interpretation by combining topographic and confocal analysis for 3D imaging.

The LabSpec™ 6 software suite also includes: ParticleFinder™ for particle analysis, SmartSampling™ for ultrafast image generation, ProtectionPlus™ for user profile management and data traceability, and an Easy Navigation package (NavMap™, NavSharp™, ViewSharp™) for advanced multimodal imaging.

LabRAM Soleil™ is designed to be both robust and modular, with simple addition of a circuit board, sensor, imaging system or a diffraction grating turret. Its modular design lets the user switch from an open space to an upright configuration in minutes. Everything has been designed to ensure quick setup of the initial system and future upgrades, backed up by premium service available around the world.

LabRAM Soleil™ also aims to be easy to maintain with a progressive maintenance plan. The instrument design ensures easy access to all parts to minimize service downtime. Customers are offered a standard 2-year warranty, including lasers and detectors, and can customize warranty conditions and maintenance contract extensions through their local HORIBA representative.

LabRAM Soleil™ Raman microscope can be coupled to OmegaScope™, HORIBA’s Atomic Force Microscope (AFM) system, available in different controlled environments, and get access spectroscopic measurements at the nanoscale.
