Arc™ Premier LC System

The Arc™ Premier LC System allows users to see clearly and consistently, with confidence. Today’s scientists and lab managers need to confidently produce the most accurate, reliable, and reproducible data. The Arc Premier System produces correct, robust results from the very first injection, reliably and easily. The Arc Premier System features the new, innovative solution of MaxPeak High Performance Surfaces (HPS) Technology, which effectively reduces non-specific adsorption due to metal interaction — without complicated mobile phases or laborious methods. The Arc Premier System sharpens chromatographic peaks for metal-sensitive compounds by eliminating secondary interactions from metals, so you can support meeting compliance standards with higher quality data, achieve faster, more reproducible, and accurate data integration, and shorten time from sample to result by eliminating the need for system conditioning.
See your sample clearly - Get the full picture of your sample with MaxPeak HPS Technology, which provides up to 10x improvements in assay-to-assay precision, up to 5x improvements in sensitivity, and 30% faster data processing for metal sensitive compounds.
Flexibly blend multiple solvents - Blend from four up to nine solvents in any combination or proportion with multi-solvent blending with the Quaternary Solvent Manager (QSM). Blend accurately at a constant pressure of up to 9500 psi throughout the flow rate range with the Binary Solvent Manager (BSM-R).
Get high-precision injections with direct inject sampling - The needle-in-flow path design ensures an accurate needle seal at high pressure for injection volumes from 0.1 μL up to 1 mL. Achieve ultra-low carryover (≤0.002%) through programmable method settings – for compatibility with even the most sensitive mass spectrometers.
Achieve flexible, stable method development - Accommodate up to six columns ranging in length from 50 mm to 300 mm with a temperature range of 4 °C to 90 °C, with column manager options and optional and integrated column selection valves for fast, unattended column changeover.
Ensure stability for method transfers - Ensure method repeatability from lab to lab with stable, uniform temperature management with integrated active pre-heating options. Gradient SmartStart easily adjusts for system volume differences when transferring methods from an alternative LC system without alteration to the method table.
Eliminate manual, error-prone mobile phase solution preparation - Directly program gradients in units of pH and ionic strength with Auto●Blend Plus Technology to vary composition in the smallest increments of pH, improve day-to-day repeatability, and eliminate time-consuming manual mobile phase solution preparation.


Product Specifications
Maximum operating pressure 9500 psi
pH range 1 to 12.5
Operating flow rate range Up to 5 mL/min
Sample flow path Inert (MaxPeak HPS Technology)
Sample carryover <0.002% (Caffeine) under UV conditions
Sample compartment 4 to 40 °C
Pump options Binary, Quaternary
Solvent conditioning Active pre-heating, Passive pre-heating
Column tracking eCord Technology column information tracks and archives column usage
About Waters Corporation
Waters Corporation, a global leader in analytical instruments and software, has pioneered chromatography, mass spectrometry and thermal analysis innovations serving the life, materials, food and environmental sciences for more than 60 years. With more than 7,800 employees worldwide, Waters Corporation operates directly in 35 countries, including 14 manufacturing facilities, and with products available in more than 100 countries.
