PFAS in groundwater - A daunting environmental challenge


Per- and polyfluoroalkyl substances (PFAS) are estimated to contaminate more than 200 million Americans' drinking water
1. After decades of manufacturing and release into the environment, the potential human epidemiological toll of PFAS is only now just beginning to be grasped. PFAS have been associated with wide-ranging health effects from cancers to physiological development issues and immune system deficiencies2,3, to name just a few.


Approximately 40% of US drinking water is sourced from groundwater and an ever-increasing volume of this precious resource is being found to contain PFAS
4,5. An unholy trinity of factors has contributed:


1.
unmatched chemical persistence6

2.      long-range mobility in groundwater7

3.      near-ubiquitous use in consumer products, ranging from clothing and cookware to paper and paints8


Aqueous film-forming foams are still being used for fire suppression at aviation facilities worldwide and are particular PFAS hotspots. Consequently, PFAS have been found even in the remotest of places, including in Arctic polar bears' brain tissue
9


PFAS concentrations detected in groundwater are often quite low, in the nanograms per liter or part per trillion (ppt) range. Nevertheless, even at these low levels, there could be unacceptable health risks caused by prolonged exposure. On February 22, 2021, the United States Environmental Protection Agency (EPA) made a final determination to regulate perfluorooctanoic acid (PFOA) and perfluorooctanesulfonic acid (PFOS) under the safe drinking water act, paving the way for their designation as hazardous substances and the determination of maximum contaminant levels (MCLs)
10. Currently, the EPA lifetime health advisory limit for combined PFOA and PFOS is 70 ppt.


Ahead of the EPA, numerous states have determined PFOA and PFOS concentrations in groundwater above which remediation or other corrective action (e.g., risk assessment) is required. Several of the state “action levels” approach ten ppt, a concentration that is equivalent to a single drop evenly dispersed in two Olympic swimming pools. Effectively addressing the confounding volume of impacted groundwater that poses a risk and reducing PFAS below the ppt-level concentrations considered acceptable, are among the most significant challenges facing groundwater remediation professionals today.


Current methods for PFAS removal from groundwater


Activated carbon has been widely used for decades throughout the world to remove organic pollutants, mostly via mechanical groundwater extraction and filtration with sorptive media, such as granular activated carbon (GAC). This pump and treat (P&T) approach uses submersible pumps placed into screened extraction wells to create a hydraulic gradient. The rapid extraction depresses the water table and forms a groundwater capture zone, intercepting the impacted groundwater and pumping it through above-ground GAC vessels that sorb the contaminants out of the water. Clean water is typically discharged to a local public treatment works. Over time, the GAC will become saturated, or ”spent”, requiring the exchange of the spent GAC bed for new or regenerated GAC.


Historically, P&T has been an effective and reliable ex situ approach used by groundwater remediation hydrogeologists and engineers to prevent contaminant migration beyond a properly-placed line of extraction wells. There are drawbacks, however, to using a P&T approach for removing PFAS.


The use of mechanical P&T systems requires continuous maintenance to ensure operational efficiency and generates a contaminated waste stream that must be managed. P&T systems are also energy-intensive and subject to National Pollutant Discharge Elimination System (NPDES) permitting, sampling and reporting requirements to ensure the treated water is cleaned to the permitted levels.


A concern is developing around the pending “hazardous substance” designation of the spent GAC. This designation would result in spent carbon having to be managed as hazardous waste with further reporting, transportation, storage and disposal regulations in effect. Moreover, due to safe thermal incineration methods having yet to be established, recycling and disposal options may be limited for spent activated carbon.


A novel PFAS groundwater treatment technology - Colloidal activated carbon passive barriers


Over the past decade, scientists engaged in the PFAS-in-groundwater dilemma have researched, lab-tested and field-applied modified activated carbon materials to allow for the effective in situ (i.e., in place) removal of PFAS from groundwater.


The remediation approach rests on the simple concept of transforming aquifer materials into a groundwater purifying filter. This transformation occurs by injecting a modified form of activated carbon across an aquifer's vertical plane carrying the contaminants. This process forms a permeable reactive barrier (PRB) that passively treats groundwater as it naturally moves through the barrier. As the groundwater migrates across the PRB, PFAS is sorbed out of it, resulting in clean water discharge from the downgradient barrier wall face.


Figure 1:
Figure depicting an in situ CAC PRB preventing migration of PFAS to sensitive receptors. Credit: Image Courtesy of REGENESIS.


Although simple in concept, specific technological hurdles had to be cleared for the approach to be practical. The first and easiest hurdle concerns the size restrictions of the aquifer materials. Typical sandy aquifer materials have openings, called pore throats, that are in the range of 10 microns. By comparison, common GAC is often in the range of 300 microns or larger. Materials scientists first had to reduce the particle size of the activated carbon, grinding them to the size of red blood cells (1 to 2 microns) to allow them to fit through the pore throats.


Shrinking their particle size alone will not permit carbon to readily pass through soil pore throats, however. This is due to the electrostatic attraction between the particles and the aquifer materials and between the particles themselves. To clear the electrostatic attraction hurdle required the micron-scale carbon to be modified into a colloidal suspension, made possible using a proprietary, non-toxic, polymeric and molecular additive treatment that stabilizes the particles and prevents them from agglomerating. Thus, a new colloidal activated carbon (CAC) material was born.


CAC passes through soil pores without resistance as the injected suspension propagates away from a delivery point (e.g., injection well or borehole). As the CAC moves through the aquifer materials, it also coats them with a thin carbon paint that encapsulates individual soil grains and leaves behind an immense surface area for chemical sorption. The single-micron CAC particle size also results in rapid kinetics for PFAS sorption, essentially removing them from groundwater immediately upon contact
11. As PFAS are removed from groundwater in situ, the drinking water ingestion exposure pathway is eliminated, and so is the risk.


Figure 2:
Scanning electron microscope image of sand grains before CAC treatment. Credit: Image Courtesy of REGENESIS.


Figure 3:
Scanning electron microscope image of sand grains after CAC treatment. Credit: Image Courtesy of REGENESIS.


The emergent in situ PFAS removal approach using the CAC technology has demonstrated success in the field for nearing five years to-date. As verified by independent researchers, typical CAC PRB applications are designed to be effective for decades
12. If, however, PFAS were to exceed the sorption capacity over time and break through, a second PRB can be installed downstream of the first to continue PFAS removal from the aquifer.


There are no known practical, safe methods for the chemical destruction of PFAS. Therefore, full-scale treatment of PFAS-impacted liquids or solids is currently limited to sequestration technologies that remove or bind PFAS but do not destroy them
13. However, there is active research evaluating methods for the destruction of PFAS, including a new startup funded by Bill Gates and other investors. As these treatment methods are developed, the in situ CAC treatment may enhance their effectiveness by concentrating the contaminants into a smaller volume of the aquifer, making PFAS easier to target and treat. CAC is commonly used for this sorption-enhanced destruction approach to treat other organic contaminants such as chlorinated solvents and petroleum hydrocarbons.


Treating the problem using this novel in situ method avoids long-term excessive maintenance costs for P&T systems. It also avoids the generation of waste streams that are soon to be deemed hazardous, making it a greener and more sustainable approach.


There are now over 100 PFAS removal projects in various planning and implementation stages as the adoption of the CAC technology increases worldwide.


References

1.         Andrews DQ, Naidenko OV. Population-Wide Exposure to Per- and Polyfluoroalkyl Substances from Drinking Water in the United States. Environ Sci Technol Lett. 2020;7(12):931-936. doi:10.1021/acs.estlett.0c00713

2.         Looker C, Luster MI, Calafat AM, et al. Influenza Vaccine Response in Adults Exposed to Perfluorooctanoate and Perfluorooctanesulfonate. Toxicological sciences : an official journal of the Society of Toxicology. 2014;138(1):76. doi:10.1093/toxsci/kft269

3.         C8 Science Panel Website. Accessed March 2, 2021. http://www.c8sciencepanel.org/prob_link.html

4.         Groundwater | Groundwater facts. Accessed February 23, 2021. https://www.ngwa.org/what-is-groundwater/About-groundwater/groundwater-facts

5.         Groundwater | Groundwater and PFAS. Default. Accessed March 2, 2021. https://www.ngwa.org/what-is-groundwater/groundwater-issues/Groundwater-and-PFAS

6.         Cousins IT, DeWitt JC, Glüge J, et al. The high persistence of PFAS is sufficient for their management as a chemical class. Environ Sci: Processes Impacts. 2020;22(12):2307-2312. doi:10.1039/D0EM00355G

7.         Modeling the Movement of PFAS Plumes in Groundwater. Inside Battelle. Accessed March 2, 2021. https://inside.battelle.org/blog-details/modeling-the-movement-of-pfas-plumes-in-groundwater

8.         EWG-AvoidingPFCs.pdf. Accessed March 2, 2021. https://static.ewg.org/ewg-tip-sheets/EWG-AvoidingPFCs.pdf

9.         Greaves AK, Letcher RJ, Sonne C, Dietz R. Brain region distribution and patterns of bioaccumulative perfluoroalkyl carboxylates and sulfonates in East Greenland polar bears (Ursus maritimus). Environmental Toxicology and Chemistry. 2013;32(3):713-722. doi:https://doi.org/10.1002/etc.2107

10.       1-29-21 - Letter - PFAS TF Priorities (Biden).pdf. Accessed February 25, 2021. https://dankildee.house.gov/sites/dankildee.house.gov/files/1-29-21%20-%20Letter%20-%20PFAS%20TF%20Priorities%20%28Biden%29.pdf

11.       Sorption of Poly- and Perfluoroalkyl Substances (PFASs) Relevant to Aqueous Film-Forming Foam (AFFF)-Impacted Groundwater by Biochars and Activated Carbon | Environmental Science & Technology. Accessed March 2, 2021. https://pubs.acs.org/doi/abs/10.1021/acs.est.7b00970

12.       Carey GR, McGregor R, Pham AL-T, Sleep B, Hakimabadi SG. Evaluating the longevity of a PFAS in situ colloidal activated carbon remedy. Remediation Journal. 2019;29(2):17-31. doi:https://doi.org/10.1002/rem.21593

13.       12 Treatment Technologies – PFAS — Per- and Polyfluoroalkyl Substances. Accessed March 2, 2021. https://pfas-1.itrcweb.org/12-treatment-technologies/
