Nanosensor Platform Could Advance Detection of Ovarian Cancer

Nanosensor Platform Could Advance Detection of Ovarian Cancer content piece image
Credit: Pixabay
Listen with
Register for free to listen to this article
Thank you. Listen to this article using the player above.

Want to listen to this article for FREE?

Complete the form below to unlock access to ALL audio articles.

Read time: 4 minutes

Ovarian cancer kills 14,000 women in the United States every year. It’s the fifth leading cause of cancer death among women, and it’s so deadly, in part, because the disease is hard to catch in its early stages. Patients often don’t experience symptoms until the cancer has begun to spread, and there aren’t any reliable screening tests for early detection.

A team of researchers is working to change that. The group includes investigators from Memorial Sloan Kettering Cancer Center, Weill Cornell Medicine, the University of Maryland, the National Institutes of Standards and Technology, and Lehigh University.

Two recent papers describe their advancements toward a new detection method for ovarian cancer. The approach uses machine learning techniques to efficiently analyze spectral signatures of carbon nanotubes to detect biomarkers of the disease and to recognize the cancer itself.

The first paper appeared in Science Advances in November.

“We demonstrated that a perception-based nanosensor platform could detect ovarian cancer biomarkers using machine learning,” says Yoona Yang, a postdoctoral research associate in Lehigh’s Department of Chemical and Biomolecular Engineering and co-first author of the paper along with Zvi Yaari, postdoctoral research fellow at Memorial Sloan Kettering Cancer Center in New York. The authors also included Ming Zheng, a research chemist at the National Institute of Standards and Technology, Anand Jagota, a professor of bioengineering and chemical and biomolecular engineering at Lehigh University, and Daniel Heller, associate member and head of the Cancer Nanotechnology Laboratory at Memorial Sloan Kettering Cancer Center.

Jagota, who also serves as associate dean of research for Lehigh’s College of Health, and Yang are members of Lehigh’s Nano | Human Interfaces Presidential Initiative, a multidisciplinary research initiative that aims to change the way we work with data and the sophisticated instruments of scientific discovery.

Traditionally, detecting biomarkers for disease requires a molecular recognition molecule like an antibody to be matched with each marker. But for ovarian cancer, there’s not a single biomarker—or analyte—that indicates the presence of cancer. When multiple analytes need to be measured in a given sample, which can increase the accuracy of a test, more antibodies are required, which increases the cost of the test and the turnaround time.

“Perception-based sensing functions like the human brain,” says Yang. “The system consists of a sensing array that captures a certain feature of the analytes in a specific way, and then the ensemble response from the array is analyzed by the computational perceptive model. It can detect various analytes at once, which makes it much more efficient.”

For this particular study, the array consisted of single-wall carbon nanotubes wrapped in strands of DNA. The way in which the DNA was wrapped, and the variety of DNA sequences that were used, created a diversity of surfaces on the nanotubes. The diverse surfaces, in turn, attracted a range of proteins within a uterine lavage sample enriched with varying levels of ovarian cancer biomarkers.

“Carbon nanotubes have interesting electronic properties,” says Heller. “If you shoot light at them, they emit a different color of light, and that light’s color and intensity can change based on what’s sticking to the nanotube. We were able to harness the complexity of so many potential binding interactions by using a range of nanotubes with various wrappings. And that gave us a range of different sensors that could all detect slightly different things, and it turned out they responded differently to different proteins.”

The machine learning algorithm was trained using the data from the nanotube emission—the spectral signatures—to recognize the pattern of emission that signaled the presence and concentration of each biomarker.

“The mental breakthrough here is that these nanotubes are nonspecific sensors,” says Jagota. “They don’t know anything about biomarkers, meaning they aren’t programmed to bind to anything specific. All we knew is that they can be exposed to an aqueous medium, and whatever they’re exposed to within that medium will produce spectral shifts and changes in magnitude. And using a combination of these sensors, we were able to train the algorithm to mathematically transform these inputs to outputs with high accuracy. It’s like having 20 sets of eyes that all see overlapping things. No single eye is that good, but as a collection, they can be trained to perform better than the existing detection methods for ovarian cancer.”

The second paper appeared in March in Nature Biomedical Engineering and comprised the work of many of the same researchers. In addition, the authors included YuHuang Wang, professor in the department of chemistry and biochemistry at the University of Maryland, and Mijin Kim, postdoctoral research associate at Memorial Sloan Kettering Cancer Center, who was lead author on the study.

“In this paper, we weren’t looking at biomarkers any longer, we were looking at the disease itself,” says Heller. “We wanted to know, could this technology differentiate a blood sample from a patient with ovarian cancer from a patient without ovarian cancer?”

Those patients without ovarian cancer included both healthy people and people with other diseases.

In this study, the nanotubes were functionalized with quantum defects, which essentially increased the diversity of responses the nanotubes would provide.

“The nanotubes had a certain molecule bound to it that gave it an extra signal in terms of data,” says Jagota. “So richer data came from every nanotube-DNA combination. And the model was trained not on the biomarker, but on the disease state.”

The model developed a “disease fingerprint” from the spectral emissions of the nanotubes. The results were statistically significant in terms of the model’s specificity in detecting ovarian cancer and sensitivity in detecting both known and unknown biomarkers of the disease.

Heller says an analogy for how the machine learning model works—in both papers—is the human nose. For example, there’s not a single odor receptor for every smell.

“Instead, there’s a bunch of different odor receptors that bind to certain molecules and create a pattern or a fingerprint of sorts,” he says. “And that pattern gets processed by your brain, which in turn, tells you what you’re smelling. So here, there’s not one particular sensor that responds to one particular thing. But, based on the pattern of different sensors responding with various changes in color and wavelength intensity, the algorithm is able to interpret what’s a biomarker and what’s not, or what’s disease and what’s not disease.”

The team has shown their technique can detect ovarian cancer better than the current methods, but it can’t yet identify early stages of the disease. In part, says Heller, the issue is finding enough samples to train the algorithm because so few people are diagnosed at those time points.

“We’re working on determining how we can actually detect this disease at the earliest possible stages,” he says.

Next steps could also include branching out to develop the technique for a range of diseases, and determining if it can be optimized to work in clinical conditions, says Jagota.

“And this is a technique that can be applied in a range of areas,” he says. “We’re focused on health, but it could be used to identify pollutants in the air, for example. There’s the potential to go after many different diseases and conditions, and I find that fascinating.”

Reference: Kim M, Chen C, Wang P, et al. Detection of ovarian cancer via the spectral fingerprinting of quantum-defect-modified carbon nanotubes in serum by machine learning. Nat Biomed Eng. 2022;6(3):267-275. doi: 10.1038/s41551-022-00860-y
