Liver Spheroids: A Major Step Towards Meaningful In Vitro Testing for Human Hepatotoxicity Potential

Liver Spheroids:  A Major Step Towards Meaningful In Vitro Testing for Human Hepatotoxicity Potential content piece image
Listen with
Register for free to listen to this article
Thank you. Listen to this article using the player above.

Want to listen to this article for FREE?

Complete the form below to unlock access to ALL audio articles.

Read time: 2 minutes

For over a decade, the pharmaceutical, chemical and cosmetics research industries have been searching for appropriate in vitro models for human toxicity testing, in order to reduce reliance on animal models and eliminate the associated cost, reliability and ethical implications. The development of new in vitro models to replace in vivo testing has already proven quite successful for certain targets. Among these are models of the immune system and human skin, while in vitro cardiac arrhythmia models are poised to emerge in the near future. Despite this clear progress, an efficient model for liver organ toxicity testing still remains elusive.

Current challenges associated with conventional in vitro liver models

Until recently, standard 2D cell culture of cancer cell lines, such as the hepatoma-derived HepG2 cells, has served as an acceptable model for acute liver cellular toxicity testing. However, many liver toxicity-inducing drugs do not exhibit classic acute cellular toxicity. Instead, mechanisms requiring prolonged exposure and multiple signaling pathways tend to be the norm, rather than the exception, when it comes to drug-induced liver injury. Moreover, many liver toxicities are idiopathic in nature where a specific cause or mechanism is not identifiable. As a result, even with the current combination of animal testing and 2D cell culture models, many liver-toxic chemicals are still making it into late clinical development and even to market.

One prevailing idea of the right type of model that would fill the current gaps of animal models and 2D cell culture would be a 3D tissue-like model made with human primary cells. Such a system would more reliably mimic the human in vivo conditions. It would likely require all of the different cell types of the liver and some sort of structure to enable the cells to work identically as they would in the human body.

To date, many complex in vitro liver systems have been developed and presented to the market, including micro-patterned co-cultures, complex mixed cell cultures, 3D printed liver tissues and various microfluidic systems. However, many of those systems have proven laborious to develop, expensive to implement and have made only incremental advancements over their predictive potential. Perhaps the thinking behind those systems has been that the liver is a complex tissue and therefore, the best in vitro model would also need to be complex. But in reality, the most appropriate in vitro model for evaluating human toxicity simply needs to be the one that is the most predictive, regardless of complexity.

How could liver spheroids help address the challenges?

One very elegant approach is the simple formation of a cell spheroid from primary human hepatocytes. Most recently, researchers at Genentech and Karolinska Institute have demonstrated that by using an inexpensive, commercially available round-bottom, low-attachment 96-well culture plate and a vial of primary human hepatocytes, it becomes possible to create 96 small liver micro-tissues with the ability to accurately predict liver toxicity 70–80% of the time. While this might not sound too impressive, we should consider that the combination of rodents and other animal models in preclinical stages boasts roughly the same predictive accuracy at hundreds of times the cost.

Primary human hepatocytes self-assembled into a spheroid containing 1500 cells after 7 days in culture (brightfield image) © Lonza Basel, Switzerland

Although the research results to date are promising, many questions remain before considering replacing animal hepatotoxicity testing with liver spheroids:

  • Is the prediction potential sufficient? Historical data of the prediction potential of animal models is well known and documented, however is the 70–80% predictive accuracy of spheroids sufficient to warrant replacement?
  • Are there certain molecular structures that cause toxicity in humans which spheroids miss, but animal studies can detect? As it is absolutely necessary to ensure that liver spheroids can accurately detect the toxicity of specific chemical groups, we should explore whether the level of predictive accuracy of spheroids could be improved by adding other liver cell types into the spheroid formation. In other words, hepatocyte-only spheroids may still miss the idiopathic mechanisms that are arguably the most likely ones to escape current screening.
  • Is the cost-benefit ratio attractive enough to consider liver cell spheroids as a first-tier testing for hepatotoxicity potential?
  • Is a single one-to-one replacement of an animal model sufficient, or will toxicologists need to implement multiple tests as replacements? If that’s the case, then the cost of a single in vitro test becomes almost irrelevant. Instead, the total cost of all the in vitro tests required to replace an animal study will be the most important figure to consider.

These questions and many more will be addressed in the coming years as more researchers and programs start working with in vitro liver models, in particular spheroid cultures, and report their findings. We look forward to seeing the progress over the next year or two.
