Mapping neurons to improve the treatment of Parkinson's

Researchers map a neural circuit responsible for motor impairment in patients with Parkinson's disease -

Because billions of neurons are packed into our brain, the neuronal circuits that are responsible for controlling our behaviors are by necessity highly intermingled. This tangled web makes it complicated to determine exactly which circuits do what. Now, using two laboratory techniques pioneered in part at California Institute of Technology (Caltech), Caltech researchers have mapped out the pathways of a set of neurons responsible for the kinds of motor impairments—such as difficulty walking—found in patients with Parkinson's disease.

The work—from the laboratory of Viviana Gradinaru, assistant professor of biology and biological engineering—is published in the journal Neuron.

See Also: MRI brain scans detect people with early Parkinson's

In patients with Parkinson's disease, gait disorders and difficulty with balance are often caused by the degeneration of a specific type of neuron—called cholinergic neurons—in a region of the brainstem called the pedunculopontine nucleus (PPN). Damage to this same population of neurons in the PPN is also linked to reward-based behaviors and disorders, such as addiction.

Previously, researchers had not been able to untangle the neural circuitry originating in the PPN to understand how both addictions and Parkinson's motor impairments are modulated within the same population of cells. Furthermore, this uncertainty created a barrier to treating those motor symptoms. After all, deep brain stimulation—in which a device is inserted into the brain to deliver electrical pulses to a targeted region—can be used to correct walking and balance difficulties in these patients, but without knowing exactly which part of the PPN to target, the procedure can lead to mixed results.

"The circuits responsible for controlling our behaviors are not nicely lined up, where this side does locomotion and this side does reward," Gradinaru says, and this disordered arrangement arises from the way neurons are structured. Much as a tree extends into the ground with long roots, neurons are made up of a cell body and a long string-like axon that can diverge and project elsewhere into different areas of the brain. Because of this shape, the researchers realized they could follow the neuron's "roots" to an area of the brain less crowded than the PPN. This would allow them to more easily look at the two very different behaviors and how they are implemented.

Cheng Xiao, a senior research scientist at Caltech and first author on the study, began by mapping the projections of the cholinergic neurons in the PPN of a rat using a technique developed by the Gradinaru lab called Passive CLARITY Technique, or PACT. In this technique, a solution of chemicals is applied to the brain; the chemicals dissolve the lipids in the tissue and render that region of the brain optically transparent and able to take up fluorescent markers that can label different types of neurons. The researchers could then follow the path of the PPN neurons of interest, marked by a fluorescent protein, by simply looking through the rest of the brain.

Learn More: Researchers map neural circuit involved in combining multiple senses

Using this method, Gradinaru and Xiao were able to trace the axons of the PPN neurons as they extended into two regions of the midbrain: the ventral substantia nigra, a landmark area for Parkinson's disease that had been previously associated with locomotion; and the ventral tegmental area, a region of the brain that had been previously associated with reward.

Next, the researchers used an electrical recording technique to keep track of the signals sent by PPN neurons—confirming that these neurons do, in fact, communicate with their associated downstream structures in the midbrain. Then, the scientists went on to determine how this specific population of neurons affects behavior. To do this, they used a technique that Gradinaru helped develop called optogenetics, which allows researchers to manipulate neural activities—in this case, by either exciting or inhibiting the PPN neural projections in the midbrain—using different colors of light.

Using the optogenetic approach in rats, the researchers found that exciting the neuronal projections in the ventral substantia nigra would stimulate the animal to walk around its environment; by contrast, they could stop the animal's movement by inhibiting these same projections. Furthermore, they found that they could stimulate reward-seeking behavior by exciting the neuronal projections in the ventral tegmental area, but could cause aversive behavior by inhibiting these projections.

"Our results show that the cholinergic neurons from the PPN indeed have a role in controlling both behaviors," Gradinaru says. "Although the neurons are very densely packed and intermingled, these pathways are, to some extent, dedicated to very specialized behaviors." Determining which pathways are associated with which behaviors might also improve future treatments, she adds.

Don't Miss: Switching off brain circuit renders mice “out of touch” with environment

"In the past it's been difficult to target treatment to the PPN because the specific neurons associated with different behaviors are intermingled at the source—the PPN. Our results show that you could target the axonal projections in the substantia nigra for movement disorders and projections in the ventral tegmental area for reward disorders, as addiction is," Gradinaru says. In addition, she notes, these projections in the midbrain are much easier to access surgically than their source in the PPN.

Although this new information could inform clinical treatments for Parkinson's disease, the PPN is only one region of the brain and there are many more important examples of connectivity that need to be explored, Gradinaru says. "These results highlight the need for brain-wide functional and anatomical maps of these long-range neuronal projections; we've shown that tissue clearing and optogenetics are enabling technologies in the creation of these maps."

Note: Material may have been edited for length and content. For further information, please contact the cited source.

California Institute of Technology   press release

Publication

Xiao C et al. Cholinergic mesopontine signals govern locomotion and reward through dissociable midbrain pathways.  Neuron, Published April 20 2016. doi: 10.1016/j.neuron.2016.03.028
