Hamamatsu Photonics K.K. has announced the completion of a new building at its Main Factory for the development and mass production of MOEMS-based opto-semiconductor devices and modules by its Solid State Division.

Subscribe to Technology Networks updates for FREE and get:

  • Daily Breaking Science News
  • Tailored newsletters
  • Exclusive eBooks, infographics and online events
 Subscribe Now

The advanced products to be made at the facility will be for automotive use, smartphones, and various other applications.

Operations at the new Building No. 13 are scheduled to begin in September. A completion ceremony for the new building was held on the 14th May 2014.
